5-40L PLC Controlled Plastic Barrel Jerrycan Small Hole Automatic Liquid Machine Chemical Cleaning Honey Oil Gear Motor Bottle

Name: 540L PLC Controlled Plastic Barrel Jerrycan Small Hole Automatic Liquid Machine Chemical Cleaning Honey Oil Gear Motor Bottle
Brand: DAESUM
Price: 1 USD

Quality 5-40L PLC Controlled Plastic Barrel Jerrycan Small Hole Automatic Liquid Machine Chemical Cleaning Honey Oil Gear Motor Bottle for sale

Place of Origin : Shanghai, China

Brand Name : DAESUM

MOQ : 1

Voltage : 380 V, 415 V

Filling accuracy : ±0.2FS

Weight : 8000 KG

Filling volume : 5L, 10L, 18L, 20L, 25L, 30L

Process material : SS304/PTFE

Structure material : SS304/CS painted

Filling mode : 2-speed

Filling lance : short/long

Number of lances : 2/4/6

Capacity : 150-300bph

Power supply : 380V/400V/415V 50Hz/60Hz

Air supply : 0.4-0.6Mpa

Max weighing : 40kg

Filling speed : 150-300bph

Nozzle type : Fine and coarse filling, metal seal bottom valve

Contact Now

5-40L JerrryCan Automatic Chemical Cleaning Liquid Filling Machine

OVERVIEW

The filling machine is quantitative type, when operating the machine, as long as place the empty jerrycans onto the mesh conveyor, and start the filling line, the equipment will automatically perform the following process: empty jerrycans are pushed onto the chain-slat conveyor 4 at a time,empty jerrycans are conveyed to the wait filling position 2/4/6 at a time, then are pushed onto the filling scale, get tared, and 2/4/6 filling nozzles move down into the jerrycans. Nozzle bottom valves open to start immersing coarse filling and fine filling. Filling nozzles move up slowly with the liquid level, when the set value is reached, filling stops (during filling, 2/4/6 empty jerrycans reach wait filling position). Heavy jerrycans are pushed onto the conveyor, and empty jerrycans in the wait position will be pushed into filling position and start filling.

TECHNICAL PARAMETER

Max weighing	40kg (single scale)
Filling accuracy	0.2%FS (better than±30g)
Material	Organic peroxide or other chemicals
Container	Jerrycan
Filling speed	25L Jerrycan 150-300bph
Filling nozzle No.	2 or 4 or 6
Filling method	Immersing filling or above liquid surface filling
Nozzle type	Fine and coarse filling, metal seal bottom valve
Cap placing type	Automatic (optional)
Screw capping type	Automatic (fixed torque) (optional)
Process contact part material	S304
Other equipment material (frame structure, conveyor side plate)	S304,Q235A (pallet conveyor side plate, pallet magazine and etc.)
